Product Summary
The flc26xgc6r is a low power fire lighter circuit. The flc26xgc6r series have been developed especially for capacitance discharge operation. The main applications are: fuel ignitor, fuel or gas heater, gas range, cook top, barbecue, water heater, HVAC, portable ignitor, insect killers.
Parametrics
flc26xgc6r absolute maximum ratings: (1)ITRM Repetitive surge peak on state current for thyristor -30°C ≤ Tamb ≤ 120°C tp = 10μs ( note 1): 90 A; (2)dI/dt Critical rate of rise on state current -30°C ≤ Tamb ≤ 120°C: 50 A/μs; (3)Tstg Tj Storage junction temperature range Maximum junction temperature - 40 to + 150°C; (4)Tamb Operating temperature range: - 30 to + 120 °C; (5)TL Maximum lead temperature for soldering during 10s: 260 °C.
Features
flc26xgc6r features: (1)dedicated thyristor structure for capacitive discharge ignition operation; (2)high pulse current capability; (3)ac or dc operation capability with supply from the ac mains or a dc battery.
Diagrams
