Product Summary

The MC145436 is a quad SPST switch. The MC145436 is a monolithic CMOS device comprising four independently selectable switches. The MC145436 is designed on an enhanced LC2MOS process, which gives an increased signal handling capability of ±15V.

Parametrics

MC145436 absolute maximum ratings: (1) VDD to Vss: 44V; (2) VDD to GND: 25V; (3) Vss to GND: -25V; (4) VL to GND: -0.3V, 25V; (5) Analog Inputs Voltage at S, D: Vss -0.3V to VDD +0.3V; (6) Continuous Current, S or D: 30mA; (7) Pulsed Current S or D 1ms Duration, 10% Duty Cycle: 70mA; (8) Power Dissipation (Any Package) Up to +75°C: 470mW; (9) Operating Temperature: -40 to +85°C; (10) Storage Temperature Range: -65 to +150°C; (11) Lead Temperature (Soldering 10 sec) : +300°C.

Features

MC145436 features: (1) 44V supply maximum rating; (2) 15V analog signal range Low RON: 115 maximum; (3) Low leakage: 0.5 nA typical; (4) Break-before-make switching; (5) Single supply operation possible; (6) Extended plastic temperature range: 40 to +85°C; (7) Available in 16-lead PDIP/SOIC and 20-pead PLCC packages; (8) Pin compatible to DG211/DG212; (9) TTL/CMOS compatible.

Diagrams

MC145436 Pin Assignment
