Product Summary

The ZJYS81R5-2P24T-G01 is a Common Mode Filter. It is suitable for CAN-BUS system, facsimiles, modems, ISDN.

Parametrics

ZJYS81R5-2P24T-G01 absolute maximum ratings: (1)Maximum DC Current: 0.5 Amp; (2)Maximum DC Resistance: 0.15 Ohms; (3)Operating Temperature Range: - 40 C to + 125℃; (4)Termination Style: SMD/SMT; (5)Series: ZJYS; (6)Case Height: 5 mm; (7)Case Length: 9 mm; (8)Case Width: 6 mm.

Features

ZJYS81R5-2P24T-G01 features: (1)Operating temperature range covers from –40 to +125℃; (2)Non-dissolution of the abutment amounts in circuit board mounting; (3)The products contain no lead and also support lead-free soldering; (4)This product conforms to the standards that are slated to be introduced under the RoHS Directive.

Diagrams

ZJYS81R5-2P24T-G01 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
ZJYS81R5-2P24T-G01
ZJYS81R5-2P24T-G01
TDK
Common Mode Inductors (Chokes) 1000ohms 0.15ohms 0.5A
Data Sheet
0-1: $0.76
1-50: $0.58
50-100: $0.53
100-500: $0.48
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
ZJYS51R5-2P
ZJYS51R5-2P
TDK
Common Mode Inductors (Chokes) 400ohms 100MHz 50V
Data Sheet
0-1: $1.54
1-10: $0.93
10-25: $0.81
25-50: $0.70
ZJYS51R5-2PLT
ZJYS51R5-2PLT
TDK
Common Mode Inductors (Chokes) Common Mode Choke
Data Sheet
0-1: $0.85
1-25: $0.73
25-50: $0.71
50-100: $0.68
ZJYS51R5-2PT-01
ZJYS51R5-2PT-01

CHOKE COMM MODE 200 OHM 2A SMD
Data Sheet
0-1: $0.79
1-10: $0.74
10-50: $0.59
50-100: $0.56
100-500: $0.46
ZJYS51R5-4P
ZJYS51R5-4P
TDK
Common Mode Inductors (Chokes) 400ohms 100MHz 50V Choke Array
Data Sheet
0-1: $2.60
1-10: $1.58
10-25: $1.37
25-50: $1.19
ZJYS51R5-4PT-01
ZJYS51R5-4PT-01

CHOKE COMMON MODE 4ARRAY 200 OHM
Data Sheet
0-1: $1.33
1-10: $1.25
10-50: $1.01
50-100: $0.93
100-500: $0.78
ZJYS81R5-2PL25-G01
ZJYS81R5-2PL25-G01
TDK
Common Mode Inductors (Chokes) 600ohms 10MHz 80V
Data Sheet
0-1: $0.91
1-10: $0.79
10-25: $0.75
25-50: $0.65
