Product Summary
The 209-3SURSYGW 3.0mm Round Type LED Lamp contains two integral chips and is available as both bicolor and bipolar types. The applications of the 209-3SURSYGW are TV set, Monitor, Telephone, Computer.
Parametrics
209-3SURSYGW absolute maximum ratings: (1)Reverse Voltage VR: 5 V; (2)Forward Current IF: 25mA; (3)Operating Temperature Topr: -40 ~ +85 ℃; (4)Storage Temperature Tstg: -40~ +90 ℃; (5)Electrostatic Discharge(HBM)ESD: 2000 V; (6)Power Dissipation Pd: 60 mW; (7)Peak Forward Current (Duty 1/10 @1KHz)IF: 160 mA.
Features
209-3SURSYGW features: (1)two chips are matched for uniform light output, wide viewing angle; (2)long life-solid state reliability; (3)I.C. compatible/low power consumpation.
Diagrams
