Product Summary
The lp104v1 is a DC/DC Converter.
Parametrics
lp104v1 general specifications: (1)Isolation Voltage: 500VDC min.; (2)Isolation Resistance: 109ohms min.; (3)Switching Frequency: 100kHz; (4)Case Grounding: Capacity Coupled to Input; (5)Operating Temperature Range: -25℃ to +71℃; (6)Storage Temperature Range: -55℃ to +125℃; (7)EM/RFI: Six-sided Continuous Shield; (8)Dimensions: 2.56 x 3.0 x 0.40 inches(65 x 76.2 x 10.2 mm); (9)Case Material: Black Coated Copper with Non-Conductive Base.
Features
lp104v1 features: (1)2:1 Input Range; (2)External Output Trim; (3)Isolated Outputs; (4)Remote Disable; (5)Efficiency to 84%; (6)Six-sided Shield; (7)100 kHz Switching Frequency; (8)PCB Mountable.
Diagrams
