Product Summary
The 1.5SMC350A is a silicon avalanche diode.
Parametrics
1.5SMC350A absolute maximum ratings: (1)Peak pulse power dissipation on 10/1000μs waveform (Note 1.2,FIG.1): Min 1500 Watts; (2)Peak pulse current of on 10/1000μs waveform (Note 1, FIG.3): See Table 1 Amps; (3)Peak forward surge current, 8.3ms single half sine-wave superimposed on rated load, (JEDEC Method)(Note3): 200 Amps; (4)Operating junction and Storage temperature range: -55 to +150 °C.
Features
1.5SMC350A features: (1)RoHS compliant; (2)For surface mounted applications in order to optimize board space; (3)Low profile package; (4)Built-in strain relief; (5)Glass passivated junction; (6)Low Inductance; (7)Excellent clamping capability; (8)Repetition Rate (duty cycle):0.05%; (9)Fast response time: typically less than 1.0ps from 0 Volts to BV min; (10)Typical IR less than 1μA above 10V; (11)High temperature soldering: 250°C/10 seconds at terminals.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 1.5SMC350A |
Littelfuse |
TVS Diodes - Transient Voltage Suppressors 1.5SMC350A |
Data Sheet |
|
|
||||||||||||
 |
1.5SMC350A/57T |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 1500W 350V Unidirect |
Data Sheet |
Negotiable |
|
||||||||||||
|
1.5SMC350A-E3/57T |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 1500W 350V Unidirect |
Data Sheet |
|
|
||||||||||||
|
1.5SMC350A-E3/51T |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 1500W 350V Unidirect |
Data Sheet |
Negotiable |
|
||||||||||||
|
1.5SMC350A-E3/59T |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 1500W 350V Unidirect |
Data Sheet |
Negotiable |
|
||||||||||||
|
1.5SMC350A/9AT |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 1500W 350V Unidirect |
Data Sheet |
Negotiable |
|
||||||||||||
|
1.5SMC350AHE3/57T |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 1500W 350V 5% Unidir |
Data Sheet |
|
|
||||||||||||
|
1.5SMC350AHE3/9AT |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 1500W 350V 5% Unidir |
Data Sheet |
|
|
||||||||||||
