Product Summary
The ZHCS1006TA is a silicon high current schottky barrier diode ”superbat”. Applications are: (1)mobile telecomms, pcmia & scsi; (2)dc-dc conversion.
Parametrics
ZHCS1006TA absolute maximum ratings: (1)continuous reverse voltage vr: 60 v; (2)forward current if: 900 ma; (3)forward voltage @ if = 1000ma(typ)vf: 600 mv; (4)average peak forward current;d.c.= 50% ifav: 1600 ma; (5)non repetitive forward current t£100ms t≦10ms ifsm: 12 A; 5 A; (6)power dissipation at tamb= 25°c ptot: 500 mw; (7)storage temperature range tstg: -55 to + 150 ° c; (8)junction temperature tj: 125 ° c.
Features
ZHCS1006TA features: (1)high current capability; (2)low vf.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 ZHCS1006TA |
Diodes Inc. / Zetex |
Schottky (Diodes & Rectifiers) VR=60V IF=0.9A IR=50uA |
Data Sheet |
Negotiable |
|
||||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||||
 |
ZHCS1000 |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
|
ZHCS1000TA |
Diodes Inc. |
Schottky (Diodes & Rectifiers) 1A Schottky 40V |
Data Sheet |
|
|
||||||||||||
|
ZHCS1000TC |
Diodes Inc. / Zetex |
Schottky (Diodes & Rectifiers) VR=40V IF=1.0A IR=50uA |
Data Sheet |
|
|
||||||||||||
|
ZHCS1006 |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
|
ZHCS1006TA |
Diodes Inc. / Zetex |
Schottky (Diodes & Rectifiers) VR=60V IF=0.9A IR=50uA |
Data Sheet |
Negotiable |
|
||||||||||||
|
ZHCS1006TC |
Diodes Inc. / Zetex |
Schottky (Diodes & Rectifiers) VR=40V IF=0.9A IR=50uA |
Data Sheet |
Negotiable |
|
||||||||||||
