Product Summary

The DS26LS31CM is a quad high speed differential line driver designed for digital data transmission over balanced lines. It is designed to provide unipolar differential drive to twisted-pair or parallel-wire transmission lines. The inputs are all LS compatible and are all one unit load.

Parametrics

DS26LS31CM absolute maximum ratings: (1)supply voltage: 7V; (2)input voltage: 7V; (3)output voltage: 5.5V; (4)output voltage-power OFF: -0.25 to 6V; (5)maximum power dissipation at 25℃: 1509mW.

Features

DS26LS31CM features: (1)output skew-2ns typical; (2)input to output delay-10ns typical; (3)operation from single 5V supply; (4)outputs wont load line when VCC=0V; (5)complementary outputs.

Diagrams

DS26LS31CM block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
DS26LS31CM
DS26LS31CM
National Semiconductor (TI)
Bus Receivers
Data Sheet
0-816: $0.54
816-1008: $0.43
1008-2544: $0.40
2544-5040: $0.38
