Product Summary
The LA6584-TLM-E is a Single-phase bipolar fan motor. It is put into silent driving by means of BTL output linear drive, offering high efficiency and power saving by suppressing the reactive current. Lock protection and rotation signal (FG, RD) circuits are built in, ensuring optimum application to small fans for notebook PC, consumer equipment power supply, car audio system, CPU cooler, etc. that require high reliability and low noise.
Parametrics
LA6584-TLM-E absolute maximum ratings: (1)Output voltage VCC max: 15 V; (2)Allowable dissipation Pd max Mounted on a specified board: 1.1 W ; (3)Output current IOUT max: 1.2 A; (4)Output withstand voltage VOUT max: 15 V; (5)RD/FG output pin output Withstand voltage VRD/FG max: 15 V; (6)RD/FG output current IRD/FG max: 5mA; (7)HB output voltage IB max: 10 mA; (8)Operating temperature range Topr: -30 to +90℃; (9)Storage temperature range Tstg: -55 to +150℃.
Features
LA6584-TLM-E features: Single-phase full-wave driver for fan motor.
Diagrams
![]() |
