Product Summary
The LC4128V-75TN100C is a programmable superFAST high density PLD. It consists of multiple 36-input, 16-macrocell Generic Logic Blocks (GLBs) interconnected by a Global Routing Pool (GRP). Output Routing Pools (ORPs) connect the GLBs to the I/O Blocks (IOBs), which contain multiple I/O cells.
Parametrics
LC4128V-75TN100C absolute maximum ratings: (1)supply voltage: -0.5 to 5.5V; (2)output supply voltage: -0.5 to 4.5V; (3)input or I/O tristate voltage applied: -0.5 to 5.5V; (4)storage temperature: -65 to 150℃; (5)junction temperature with power applied: -55 to 150℃.
Features
LC4128V-75TN100C features: (1)Hot-socketing; (2)Open-drain capability; (3)Input pull-up, pull-down or bus-keeper; (4)Programmable output slew rate; (5)3.3V PCI compatible; (6)IEEE 1149.1 boundary scan testable; (7)3.3V/2.5V/1.8V In-System Programmable.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LC4128V-75TN100C |
Lattice |
CPLD - Complex Programmable Logic Devices 400MHZ 128 Macrocell 3.3 V 7.5 tPD |
Data Sheet |
|
|
||||||||||
