Product Summary
The LM2465TA is a High Gain CRT Driver. The LM2465TA is an integrated high voltage CRT driver circuit designed for use in color monitor applications. The IC contains three high input impedance, wide band amplifiers which directly drive the RGB cathodes of a CRT. Each channel has its gain internally set to −20 and can drive CRT capacitive loads as well as resistive loads present in other applications, limited only by the package’s power dissipation. The IC is packaged in an industry standard 9-lead TO-220 molded plastic package.
Parametrics
LM2465TA absolute maximum ratings: (1)Supply Voltage (VCC) : +90V; (2)Bias Voltage (VBB) : +16V; (3)Input Voltage (VIN) : 0V to 4.5V; (4)Storage Temperature Range (TSTG) : -65℃ to +150℃; (5)Lead Temperature (Soldering, <10 sec.) : 300℃; (6)ESD Tolerance, Human Body Model : 2 kV.
Features
LM2465TA features: (1)Higher gain to match LM126X CMOS preamplifiers; (2)0V to 3.75V input range; (3)Stable with 0–20 pF capacitive loads and inductive peaking networks; (4)Same pinout as LM2467/8/9, maintaining the standard LM243X Family pinout for easy PCB layout; (5)Convenient TO-220 staggered lead package style.
