Product Summary

The PT501A is a TO-18 Type Narrow Acceptance Phototransistor.

Parametrics

PT501A absolute maximum ratings: (1)Collector-emitter voltage VCEO 45 V; (2)Emitter-collector voltage VECO 6V; (3)Emitter-base voltage V EBO 6V; (4)Collector power dissipation PC 75mW; (5)Operating temperature T opr - 25 to + 125℃; (6)Storage temperature T stg - 55 to + 150℃; (7)Soldering temperature T sol 260℃.

Features

PT501A features: (1)Narrow acceptance); (2)With base terminal: PT510; (3)TO -18 type standard package.

Diagrams

PT501A block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
PT501A
PT501A
Sharp Microelectronics
Photodetector Transistors PT501 with Ic bin 20-80mA
Data Sheet
Negotiable
