AT49BV320D-70TU

TSOP, 2.7-volt, 32-megabit, Flash memory

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.20~1.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.20~1.50

PartNumber:: AT49BV320D-70TU

Brand:: ATMEL Corporation - ATMEL | Pack: TSOP | D/C: 05+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. hellen's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-12

From Other Seller

Part Number:AT49BV320D-70TU
US $1.20 - 1.50
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT49BV320D-70TU is a 2.7-volt 32-megabit Flash memory organized as 2,097,152 words of 16 bits each. The memory is divided into 71 sectors for erase operations. The device is offered in a 48-lead TSOP package and a 47-ball CBGA package. The AT49BV320D-70TU has CE and OE control signals to avoid any bus contention. This AT49BV320D-70TU can be read or reprogrammed using a single power supply, making it ideally suited for in-system programming. The AT49BV320D-70TU powers on in the read mode. Command sequences are used to place the device in other operation modes such as program and erase. The device has the capability to protect the data in any sector.

Parametrics

AT49BV320D-70TU absolute maximum ratings: (1)Temperature under Bias: -55℃ to +125℃; (2)Storage Temperature: -65℃ to +150℃; (3)All Input Voltages(including NC Pins) with Respect to Ground:-0.6V to +6.25V; (4)All Output Voltages with Respect to Ground: -0.6V to VCC + 0.6V; (5)Voltage on VPP with Respect to Ground: -0.6V to +10.0V.

Features

AT49BV320D-70TU features: (1)Single Voltage Read/Write Operation: 2.65V to 3.6V; (2)Access Time -0 ns; (3)Sector Erase Architecture; (4)Fast Word Program Time 10μs; (5)Fast Sector Erase Time 100 ms; (6)Suspend/Resume Feature for Erase and Program; (7)Low-power Operation; (8)VPP Pin for Write Protection and Accelerated Program Operation; (9)WP Pin for Sector Protection; (10)RESET Input for Device Initialization; (11)Flexible Sector Protection; (12)TSOP and CBGA Package Options; (13)Top or Bottom Boot Block Configuration Available; (14)128-bit Protection Register; (15)Minimum 100,000 Erase Cycles; (16)Common Flash Interface (CFI); (17)Green (Pb/Halide-free) Packaging.
