Product Summary
The SN74LVC1G11DBVR is a single 3-input positive-and gate. The SN74LVC1G11DBVR is fully specified for partial-power-down applications using Ioff.
Parametrics
SN74LVC1G11DBVR absolute maximum ratings: (1) Supply voltage range, VCC: -0.5 to 6.5V; (2) Input voltage range, VI: -0.5 to 6.5V; (3) Voltage range applied to any output in the high-impedance or power-off state, VO: -0.5 to 6.5V; (4) Voltage range applied to any output in the high or low state, VO: -0.5 to Vcc +0.5V; (5) Input clamp current, IIK (VI< 0) : -50mA; (6) Output clamp current, IOK (VO< 0) : -50mA; (7) Continuous output current, IO: ± 50mA; (8) Storage temperature range, Tstg: -65°C to 150 °C.
Features
SN74LVC1G11DBVR features: (1) Available in the Texas Instruments; (2) NanoStar and NanoFreePackages Supports 5-V VCC Operation; (3) Inputs Accept Voltages to 5.5V Max tpd of 4.1ns at 3.3V; (4) Low Power Consumption, 10- µA Max ICC ±24mA; (5) Output Drive at 3.3V Ioff; (6) Supports Partial-Power-Down Mode Operation; (7) Latch-Up Performance Exceeds 100 mA Per JESD 78, Class II; (8) ESD Protection Exceeds JESD 22; (9) 2000-V Human-Body Model (A114-A) ; (10) 200-V Machine Model (A115-A) ; (11) 1000-V Charged-Device Model (C101) .
Diagrams
