Product Summary
The ATF22V10C-7PX is a high-performance CMOS (electrically erasable) programmable logic device (PLD) that utilizes proven electrically erasable Flash memory technology from Atmel. Speeds down to 5ns and power dissipation as low as 10μA (typical) are offered. All speed ranges of the ATF22V10C-7PX are specified over the full 5V ± 10% range for military and industrial temperature ranges, and 5V ± 5% for commercial temperature ranges.
Parametrics
ATF22V10C-7PX absolute maximum ratings: (1)Temperature under Bias: -40 to +85℃; (2)Storage Temperature: -65 to +150℃; (3)Voltage on Any Pin with Respect to Ground: -2.0V to +7.0V; (4)Voltage on Input Pins with Respect to Ground during Programming: -2.0V to +14.0V; (5)Programming Voltage with Respect to Ground: -2.0V to +14.0V.
Features
ATF22V10C-7PX features: (1)Industry-standard Architecture: Low-cost, Easy-to-use Software Tools; (2)High-speed, Electrically Erasable Programmable Logic Devices: 5ns Maximum Pin-to-pin Delay; (3)Latch Feature Holds Inputs to Previous Logic States; (4)Pin-controlled Standby Power (10μA Typical); (5)Advanced Flash Technology: Reprogrammable; 100% Tested; (6)High-reliability CMOS Process: 20-year Data Retention; 100 Erase/Write Cycles; 2,000V ESD Protection; 200mA Latch-up Immunity; (7)Dual Inline and Surface Mount Packages in Standard Pinouts; (8)PCI-compliant; (9)Green Package Options (Pb/Halide-free/RoHS Compliant) Available; (10)Full Military, Commercial and Industrial Temperature Ranges; (11)Backward-Compatible with Atmel ATF22V10B(Q) and Atmel AT22V10(L); (12)Applications Include Glue Logic for 5.0V Systems, DMA Control, State Machine Control, Graphics Processing.
