Product Summary

The PS2 joystick is an Intelligent Power Module. DIP and Mini DIP-IPMs are intelligent power modules that integrate power device, driver, and protection circuitry in an ultra compact dual-in-line transfer-mold package for use in driving small three phase motor. It is ideal for: (1)Washing Machines; (2)Refrigerators; (3)Air Conditioners; (4)Small Servo Motors; (5)Small Motor Control.

Parametrics

PS2 joystick absolute maximum ratings: (1)Power Device Junction Temperature: Tj -20 to 125 °C; (2)Module Case Operation Temperature (See Tf Measurement Point Illustration)Tf -20 to 100 °C; (3)Storage Temperature Tstg -40 to 125 °C; (4)Mounting Torque, M3 Mounting Screws: 8.5 in-lb; (5)Module Weight (Typical): 20 Grams; (6)Self-protection Supply Voltage Limit (Short Circuit Protection Capability) VCC(prot.): 400 Volts; (7)Isolation Voltage, AC 1 minute, 60Hz Sinusoidal, Connection Pins to Heatsink Plate VISO: 2500 Volts.

Features

PS2 joystick features: (1)Compact Packages; (2)Single Power Supply; (3)Integrated HVICs; (4)Direct Connection to CPU.

Diagrams

PS2 joystick pin connection
