Product Summary

The bgy787b is a Hybrid amplifier module in a SOT115J package operating with a voltage supply of 24 V (DC). It is suitable for CATV systems operating in the frequency range of 40 MHz to 750 MHz.

Parametrics

bgy787b absolute maximum ratings: (1)Vi, RF input voltage: 60 dBmV; (2)Tstg storage temperature: -40 to +100℃; (3)Tmb mounting base temperature: -20 to +100℃.

Features

bgy787b features: (1)Extremely low noise; (2)Silicon nitride passivation; (3)Rugged construction; (4)Gold metallization ensures excellent reliability; (5)Excellent linearity.

Diagrams

bgy787b diagram
