TIM0910-5

TIM0910-5, microwave power GaAs FET, 15V, 40.5W, 5.7A, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $4.15~4.17 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	4.17 / Piece
101 ~ 1000 :	4.16 / Piece
1001 ~ 2000 :	4.15 / Piece

PartNumber:: TIM0910-5

Brand:: Toshiba Semiconductor - Toshiba | D/C: 13+

Availability:: Supply Ability: 2000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. hellen's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-23

From Other Seller

Part Number:TIM0910-5
US $4.15 - 4.17
Quantity:

piece

Product Summary

The tim0910-5 is a microwave power GaAs FET.

Parametrics

tim0910-5 absolute maximum ratings: (1)Drain-Source Voltage VDS: 15V; (2)Gate-Source Voltage VGS: -5V; (3)Drain Current IDS: 5.7A; (4)Total Power Dissipation (Tc= 25 °C)PT: 40.5W; (5)Channel Temperature Tch: 175°C; (6)Storage Temperature Tstg: -65 to +175°C.

Features

tim0910-5 features: (1)high power: P1dB=37.5dBm at 9.5GHz to 10.5GHz; (2)broad band internallymatched; (3)high gain: G1dB=7.0dB at 9.5GHz to 10.5GHz; (4)hermetically sealed package.
