TIM1112-8

tim1112-8, power gaas fet, 15 v, 60 W, 29.0dB, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $5.96~5.96 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	5.96 / Piece

PartNumber:: TIM1112-8

Brand:: Toshiba Semiconductor - Toshiba | D/C: 13+

Availability:: Supply Ability: 2000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. hellen's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-23

From Other Seller

Part Number:TIM1112-8
US $5.96 - 5.96
Quantity:

piece

Product Summary

The tim1112-8 is a microwave power gaas fet.

Parametrics

tim1112-8 absolute maximum ratings: (1)Drain-Source Voltage VDS: 15 v; (2)Gate-Source Voltage VGS : -5 V; (3)Drain Current IDS: 11.5 A; (4)Total Power Dissipation (Tc= 25 °C)PT: 60 W; (5)Channel Temperature Tch: 175°C; (6)Storage Temperature Tstg: -65 to +175°C.

Features

tim1112-8 features: (1)LOW INTERMODULATION DISTORTION IM3=-45 dBc at Pout= 29.0dB; (2)HIGH POWER P1dB=40.5dBm at 10.7GHz to 11.7GHz; (3)HIGH GAIN G1dB=6.0 dB at 10.7 GHz to 11.7GH; (4)BROAD BAND INTERNALLY MATCHED FET; (5) HERMETICALLY SEALED PACKAG.
