TIM1414-4

tim1414-4, power GaAs FET, 15V, 5.2A, 42.8W, dip

Rated 5 Rating 5 | reviews | Write a review

Price:: US $8.52~8.54 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	8.54 / Piece
101 ~ 1000 :	8.53 / Piece
1001 ~ 2000 :	8.52 / Piece

PartNumber:: TIM1414-4

Brand:: Toshiba Semiconductor - Toshiba | D/C: 06+

Availability:: Supply Ability: 2000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. hellen's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-23

From Other Seller

Part Number:TIM1414-4
US $8.52 - 8.54
Quantity:

piece

Product Summary

The tim1414-4 a microwave power GaAs FET.

Parametrics

tim1414-4 absolute maximum ratings: (1)Drain-Source Voltage VDS: 15V; (2)Gate-Source Voltage VGS: -5V; (3)Drain Current IDS: 5.2A; (4)Total Power Dissipation (Tc= 25 °C)PT: 42.8W; (5)Channel Temperature Tch: 175°C; (6)S torage Temperature Tstg: -65 to +175°C.

Features

tim1414-4 features: (1)high power: P1dB=36.0dBm at 13.75GHz to 14.5GHz; (2)broad band internally matched fet; (3)high gain: G1dB=5.5dB at 13.75GHz to 14.5GHz; (4)hermetically sealed package.
