TIM1414-4LA

tim1414-4la, microwave power GaAs FET, 15V, 30W, 5.2A

Rated 5 Rating 5 | reviews | Write a review

Price:: US $6.56~6.58 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	6.58 / Piece
101 ~ 1000 :	6.57 / Piece
1001 ~ 2000 :	6.56 / Piece

PartNumber:: TIM1414-4LA

Brand:: Toshiba Semiconductor - Toshiba | D/C:

Availability:: Supply Ability: 2000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. hellen's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-23

From Other Seller

Part Number:TIM1414-4LA
US $6.56 - 6.58
Quantity:

piece

Product Summary

The tim1414-4la is a microwave power GaAs FET.

Parametrics

tim1414-4la absolute maximum ratings: (1)Drain-Source Voltage VDS: 15V; (2)Gate-Source Voltage VGS: -5V; (3)Drain Current IDS: 5.2A; (4)Total Power Dissipation (Tc= 25 °C)PT: 30W; (5)Channel Temperature Tch: 175°C; (6)Storage Temperature Tstg: -65 to +175°C.

Features

tim1414-4la features: (1)high power: p1db=36.5dbm at 14.0ghz to 14.5ghz; (2)broad band internally matched; (3)high gain: g1db=6.5db at 14.0ghz to 14.5ghz; (4)hermetically sealed package.
