TIM5964-35SLA

tim5964-35sla, Toshiba, GaAs FET, 15V, 26A, 115W

Rated 5 Rating 5 | reviews | Write a review

Price:: US $6.57~6.59 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	6.59 / Piece
101 ~ 1000 :	6.58 / Piece
1001 ~ 2000 :	6.57 / Piece

PartNumber:: TIM5964-35SLA

Brand:: Toshiba Semiconductor - Toshiba | D/C: 13+

Availability:: Supply Ability: 2000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. hellen's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-24

From Other Seller

Part Number:TIM5964-35SLA
US $6.57 - 6.59
Quantity:

piece

Product Summary

The tim5964-35sla is a microwave power GaAs FET.

Parametrics

tim5964-35sla absolute maximum ratings: (1)Drain-Source Voltage VDS: 15V; (2)Gate-Source Voltage VGS: -5V; (3)Drain Current IDS: 26.0A; (4)Total Power Dissipation (Tc= 25 °C)PT: 115W; (5)Channel Temperature Tch: 175°C; (6)Storage Tstg: -65 to +175°C.

Features

tim5964-35sla features: (1)Low intermodulation distortion- IM3= -45 dBc at Po = 35.0dBm, Single carrier level; (2)High power- P1dB = 45.5 dBm at 5.9ghz to 6.75ghz; (3)High gain- G1dB = 8.5dB at 5.9ghz to 6.75ghz; (4)Broad band internally matched; (5)Hermetically sealed package.
