TIM6472-12UL

tim6472-12ul, microwave power GAAS FET, 15V, 10.0A, 62.5W

Rated 5 Rating 5 | reviews | Write a review

Price:: US $7.46~7.48 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	7.48 / Piece
101 ~ 1000 :	7.47 / Piece
1001 ~ 2000 :	7.46 / Piece

PartNumber:: TIM6472-12UL

Brand:: Toshiba Semiconductor - Toshiba | D/C: 13+

Availability:: Supply Ability: 2000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. hellen's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-24

From Other Seller

Part Number:TIM6472-12UL
US $7.46 - 7.48
Quantity:

piece

Product Summary

The tim6472-12ul is a microwave power GAAS FET.

Parametrics

tim6472-12ul absolute maximum ratings: (1)Drain-Source Voltage VDS: 15V; (2)Gate-Source Voltage VGS: -5V; (3)Drain Current IDS: 10.0A; (4)Total Power Dissipation (Tc= 25 °C)PT: 62.5W; (5)Channel Temperature Tch: 175°C; (6)Storage Temperature Tstg: -65 to +175°C.

Features

tim6472-12ul features: (1)high power: p1db=41.5dbm at 6.4ghz to 7.2ghz; (2)broad band internally matched; (3)high gain: g1db=9.5db at 6.4ghz to 7.2ghz; (4)hermetically sealed package.
