TIM6472-35SL

TIM6472-35SL, microwave power GaAs FET, 15V, 115.4 W, 20A, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $9.41~9.43 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	9.43 / Piece
101 ~ 1000 :	9.42 / Piece
1001 ~ 2000 :	9.41 / Piece

PartNumber:: TIM6472-35SL

Brand:: Toshiba Semiconductor - TOSHIBA | D/C: 13+

Availability:: Supply Ability: 2000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. hellen's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-24

From Other Seller

Part Number:TIM6472-35SL
US $9.41 - 9.43
Quantity:

piece

Product Summary

The tim6472-35sl is a microwave power GaAs FET.

Parametrics

tim6472-35sl absolute maximum ratings: (1)Drain-Source Voltage VDS: 15V; (2)Gate-Source Voltage VGS: -5V; (3)Drain Current IDS: 20A; (4)Total Power Dissipation (Tc= 25 °C)PT: 115.4 W; (5)Channel Temperature Tch: 175°C; (6)Storage Temperature Tstg: -65 to +175°C.

Features

tim6472-35sl features: (1)low intermodulation distortion: IM3=-45 dBc at Pout= 35.0dBm, single carrier level; (2)high gain: G1dB=8.0dB at 6.4GHz to 7.2GHz; (3)broadband internallymatched; (4)high power: P1dB=45.5dBm at 6.4GHz to 7.2GHz; (5)hermetically sealed package.
