TIM7785-4UL

tim7785-4ul, microwave power GAAS FET, 15V, 3.5A, 23W

Rated 5 Rating 5 | reviews | Write a review

Price:: US $6.87~6.89 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	6.89 / Piece
101 ~ 1001 :	6.88 / Piece
1001 ~ 2000 :	6.87 / Piece

PartNumber:: TIM7785-4UL

Brand:: Toshiba Semiconductor - Toshiba | D/C: 13+

Availability:: Supply Ability: 2000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. hellen's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-24

From Other Seller

Part Number:TIM7785-4UL
US $6.87 - 6.89
Quantity:

piece

Product Summary

The tim7785-4ul is a microwave power GAAS FET.

Parametrics

tim7785-4ul absolute maximum ratings: (1)Drain-Source Voltage VDS: 15V; (2)Gate-Source Voltage VGS: -5V; (3)Drain Current IDS: 3.5A; (4)Total Power Dissipation (Tc= 25 °C)PT: 23W; (5)Channel Temperature Tch: 175°C; (6)Storage Temperature Tstg: -65 to +175°C.

Features

tim7785-4ul features: (1)high power: p1db=36.5dbm at 7.7ghz to 8.5ghz; (2)broad band internally matched; (3)high gain: g1db=8.5db at 7.7ghz to 8.5ghz; (4)hermetically sealed package.
