TIM7785-8SL

microwave power GAAS FET, tim7785-8sl, 15V, 7.0A, 39.5W

Rated 5 Rating 5 | reviews | Write a review

Price:: US $9.46~9.48 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	9.48 / Piece
101 ~ 1000 :	9.47 / Piece
1001 ~ 2000 :	9.46 / Piece

PartNumber:: TIM7785-8SL

Brand:: Toshiba Semiconductor - Toshiba | D/C: 13+

Availability:: Supply Ability: 2000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. hellen's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-24

From Other Seller

Part Number:TIM7785-8SL
US $9.46 - 9.48
Quantity:

piece

Product Summary

The tim7785-8sl is a microwave power GAAS FET.

Parametrics

tim7785-8sl absolute maximum ratings: (1)Drain-Source Voltage VDS: 15V; (2)Gate-Source Voltage VGS: -5V; (3)Drain Current IDS: 7.0A; (4)Total Power Dissipation (Tc= 25 °C)PT: 39.5W; (5)Channel Temperature Tch: 175°C; (6)Storage Temperature Tstg: -65 to +175°C.

Features

tim7785-8sl features: (1)Low intermodulation distortion- IM3= -45 dBc at Po = 28.5 dBm, Single carrier level; (2)High power- P1dB = 39.5 dBm at 7.7ghz to 8.5ghz; (3)High gain- G1dB = 6.0dB at 7.7ghz to 8.5ghz; (4)Broad band internally matched; (5)Hermetically sealed package.
