Product Summary

The BTS5210G is a smart high-side power switch. It is a N channel vertical power MOSFET with charge pump. It has ground referenced CMOS compatible input and diagnostic feedback. The BTS5210G is monlithically integrated in smart SIPMOS technology. It provids embedded protective functions.

Parametrics

BTS5210G maximum ratings: (1)Supply voltage, Vbb: 43V; (2)Supply voltage for full short circuit protection, Vbb: 36V; (3)Load current, IL: self-limiled; (4)Load dump protection: 60V; (5)Operating temperature range, Tj: -40 to + 150℃; (6)Storage temperature range, Tstg: -40 to + 150℃; (7)Electrostatic discharge capability, VESD: 1.0kV.

Features

BTS5210G features: (1)Smart high-side power switch; (2)Two channels: 2 x 140mΩ; (3)Status feedback.

Diagrams

BTS5210G block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
BTS5210G
BTS5210G

Infineon Technologies

Power Switch ICs - Power Distribution SMART HI SIDE PWR SWITCH 2 CHANNELS

Data Sheet

0-1: $1.36
1-10: $1.22
10-100: $0.98
100-500: $0.76
