Product Summary
The LM360N is a very high speed differential input, complementary TTL output voltage comparator with improved characteristics over the µA760/µA760C, for which it is a pin-for-pin replacement. The LM360N has been optimized for greater speed, input impedance and fan-out, and lower input offset voltage. Typically delay varies only 3 ns for over-drive variations of 5 mV to 400 mV.
Parametrics
LM360N absolute maximum ratings: (1)Positive Supply Voltage: +8V; (2)Negative Supply Voltage: -8V; (3)Peak Output Current: 20 mA; (4)Differential Input Voltage: ±5V; (5)ESD Tolerance: 1600V; (6)Operating Temperature Range: 0 to +70℃; (7)Storage Temperature Range: -65 to +150℃; (8)Lead Temperature (Soldering, 10 sec.): 260℃.
Features
LM360N features: (1)Guaranteed high speed: 20 ns max; (2)Tight delay matching on both outputs; (3)Complementary TTL outputs; (4)High input impedance; (5)Low speed variation with overdrive variation; (6)Fan-out of 4; (7)Low input offset voltage; (8)Series 74 TTL compatible.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LM360N/NOPB |
|
IC COMPARATOR HS DIFF 8-DIP |
Data Sheet |
Negotiable |
|
||||||||||||
