LT1763IDE-2.5

micropower regulator, 500mA,1.8 to 20V, DFN

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.45~3.19 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 2 :	3.19 / Piece
2 ~ 8 :	2.45 / Piece

PartNumber:: LT1763IDE-2.5

Brand:: Linear Technology - Linear | Pack: DFN | D/C: 09+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. hellen's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-24

From Other Seller

Part Number:LT1763IDE-2.5
US $2.45 - 3.19
Quantity:

piece

Product Summary

The LT1763IDE-2.5 is a micropower, low noise, low dropout regulator. The LT1763IDE-2.5 is capable of supplying 500mA of output current with a dropout voltage of 300mV. Applications of the LT1763IDE-2.5 include: Cellular Phones, Battery-Powered Systems and Noise-Sensitive Instrumentation Systems.

Parametrics

LT1763IDE-2.5 absolute maximum ratings: (1) IN Pin Voltage:±20V;(2) OUT Pin Voltage: ±20V; (3) Input to Output Differential Voltage; (4) Input to Output Differential Voltage: ±20V; (5) SENSE Pin Voltage: ±20V; (6) ADJ Pin Voltage: ±7V; (7) BYP Pin Voltage: ±0.6V; (8) SHDN Pin Voltage: ±20V; (9) Operating Junction Temperature Range, C, I Grade: -40°C to 125°C, MP Grade: -55°C to 125°C; (10) Storage Temperature Range: -65°C to 150°C.

Features

LT1763IDE-2.5 features: (1) Low Noise: 20μVRMS (10Hz to 100kHz) ; (2) Output Current: 500mA ; (3) Low Quiescent Current: 30μA; (4) Wide Input Voltage Range: 1.8V to 20V; (5) Low Dropout Voltage: 300mV; (6) Very Low Shutdown Current: < 1μA; (7) No Protection Diodes Needed; (8) Fixed Output Voltages: 1.5V, 1.8V, 2.5V, 3V, 3.3V, 5V; (9) Adjustable Output from 1.22V to 20V; (10) Stable with 3.3μF Output Capacitor; (11) Overcurrent and Overtemperature Protected; (12) 8-Lead SO and 12-Lead (4mm × 3mm) DFN Packages.
