MIC5319-2.6YML

500mA LDO regulator, MLF-6, 0V to 6V, MIC5319-2.6YML, Micrel

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.13~0.41 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.13~0.41

PartNumber:: MIC5319-2.6YML

Brand:: Micrel Semiconductor - Micrel | Pack: MLF | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. hellen's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-11-15

From Other Seller

Part Number:MIC5319-2.6YML
US $0.13 - 0.41
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MIC5319-2.6YML is a high-performance, 500mA LDO regulator, offering extremely high PSRR and very-low noise while consuming low ground current. The applications of the device are (1)Cellular phones; (2)PDAs; (3)Fiber optic modules; (4)Portable electronics; (5)Notebook PCs; (6)Audio Codec power supplies.

Parametrics

MIC5319-2.6YML absolute maximum ratings: (1)Supply Input Voltage (VIN): 0V to 6V; (2)Enable Input Voltage (VEN): 0V to 6V; (3)Power Dissipation (PD): Internally Limited; (4)Junction Temperature (TJ): -40 to +125℃; (5)Storage Temperature (TS): -65 to +150℃; (6)Lead Temperature (soldering, 5sec.): 260℃; (7)ESD Rating: 3kV.

Features

MIC5319-2.6YML features: (1)Ultra-low dropout voltage 200mV @ 500mA; (2)Input voltage range: 2.5 to 5.5V; (3)Stable with ceramic output capacitor; (4)Low output noise: 40uVrms; (5)Low quiescent current of 90μA total; (6)High PSRR, up to 70dB @1kHz; (7)Fast turn-on-time: 40μs typical; (8)High-output accuracy; (9)Thermal-shutdown protection; (10)Current-limit protection; (11)Logic-controlled Enable; (12)Tiny 2mm x 2mm MLF package, 500mA continuous; (13)Thin SOT-23-5 package, 500mA peak.
