Product Summary

The LQW18ANR12 is a chip inductor for high frequency horizontal wire wound.

Parametrics

LQW18ANR12 specifications: (1)Inductnce=12nH±5%; (2)Test Frequency=100MHz; (3)Rated current=600mA; (4)Max. of DC resistance=0.13ohm; (5)Q min=35; (6)Test Frequency=250MHz; (7)Self resonance frequency(min.)=6000MHz.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
LQW18ANR12G00D
LQW18ANR12G00D
Murata
RF Inductors 0603 120nH +/-2% DCR 1.30ohm
Data Sheet
0-1: $0.19
1-50: $0.16
50-100: $0.15
100-500: $0.12
LQW18ANR12J00D
LQW18ANR12J00D
Murata
RF Inductors 0603 0.12uH
Data Sheet
0-1: $0.17
1-50: $0.15
50-100: $0.14
100-500: $0.11
