Product Summary
The MM74HC125M is a general purpose 3-STATE high speed non-inverting buffer utilizing advanced silicon-gate CMOS technology. The MM74HC125M has high drive current outputs which enable high speed operation even when driving large bus capacitances. These circuits possess the low power dissipation of CMOS circuitry, yet have speeds comparable to low power Schottky TTL circuits. The MM74HC125M is capable of driving up to 15 low power Schottky inputs.
Parametrics
MM74HC125M absolute maximum ratings: (1)Supply Voltage (VCC): -0.5 to +7.0V; (2)DC Input Voltage (VIN): -1.5 to VCC +1.5V; (3)DC Output Voltage (VOUT): -0.5 to VCC +0.5V; (4)Clamp Diode Current (IIK, IOK): ±20 mA; (5)DC Output Current, per pin (IOUT): ±35 mA.
Features
MM74HC125M features: (1)Typical propagation delay: 13 ns; (2)Wide operating voltage range: 2–6V; (3)Low input current: 1 μA maximum; (4)Low quiescent current: 80 μA maximum (74HC); (5)Fanout of 15 LS-TTL loads.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MM74HC125M |
Fairchild Semiconductor |
Buffers & Line Drivers 3-STATE Quad Buffers |
Data Sheet |
|
|
||||||||||||
|
MM74HC125M_Q |
Fairchild Semiconductor |
Buffers & Line Drivers 3-STATE Quad Buffers |
Data Sheet |
Negotiable |
|
||||||||||||
|
MM74HC125MTC |
Fairchild Semiconductor |
Buffers & Line Drivers 3-STATE Quad Buffers |
Data Sheet |
|
|
||||||||||||
|
MM74HC125MTCX |
Fairchild Semiconductor |
Buffers & Line Drivers 3-STATE Quad Buffers |
Data Sheet |
|
|
||||||||||||
|
MM74HC125MTC_Q |
Fairchild Semiconductor |
Buffers & Line Drivers 3-STATE Quad Buffers |
Data Sheet |
|
|
||||||||||||
|
MM74HC125MTC_NL |
Fairchild Semiconductor |
Buffers & Line Drivers 3-STATE Quad Buffers |
Data Sheet |
Negotiable |
|
||||||||||||
|
MM74HC125MX |
Fairchild Semiconductor |
Buffers & Line Drivers 3-STATE Quad Buffers |
Data Sheet |
|
|
||||||||||||
