The SG1524J is a PWM switching regulator control circuit contains all the essential circuitry to implement single-ended or push-pull switching regulators. Applications of the SG1524J include: switching power supplies, motor speed control and off-line power converter.
Parametrics
SG1524J absolute maximum ratings: (1) input voltage: 40V; (2) reference output current: 50mA; (3) output current (each output) : 100mA; (4) oscillator charging current ( pin 6 or 7) : 5mA; (5) internal power dissipation: 1W; (6) operating temperature range: -55 to +125℃; (7) storage temperature range: -65 to +150℃; (8) Lead temperature (soldering, 10 sec.) : 300℃.
Features
SG1524J features: (1) guranteed +/-2% reference tolerance; (2) guranteed +/- 6% oscillator tolerance; (3) guranteed 10mv/1000Hrs long term stability; (4) operates above 100kHz.
