SN74AHC1G04DBVR

inverter gate, 2V to 5V, ±50mA, SOT

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.15~0.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 2 :	0.20 / Piece
2 ~ 200 :	0.15 / Piece

PartNumber:: SN74AHC1G04DBVR

Brand:: Texas Instruments - TI | Pack: SOT | D/C: 10+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. hellen's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-23

From Other Seller

Part Number:SN74AHC1G04DBVR
US $0.15 - 0.20
Quantity:

piece

Product Summary

The SN74AHC1G04DBVR is a single inverter gate.

Parametrics

SN74AHC1G04DBVR absolute maximum ratings: (1) Supply voltage range, VCC: -0.5 to 7V; (2) Input voltage range, VI: -0.5 to 7V; (3) Output voltage range, VO: -0.5 to Vcc +0.5V; (4) Input clamp current, IIK (VI< 0) : -20mA; (5) Output clamp current, IOK (VO< 0 or VO> VCC) : ±20mA; (6) Continuous output current, IO (VO= 0 to VCC) : ±50mA; (7) Storage temperature range, Tstg: -65°C to 150°C.

Features

SN74AHC1G04DBVR features: (1) Operating Range of 2V to 5.5V; (2) Max tpd of 6.5ns at 5V; (3) Low Power Consumption, 10-µA Max ICC ±8-mA Output Drive at 5V; (4) Schmitt Trigger Action at All Inputs Makes the Circuit Tolerant for Slower Input Rise and Fall Time; (5) Latch-Up Performance Exceeds 250 mA Per JESD 17.
