SN74AVCH2T45DCUR

bus transceiver, 4.6V, ±100mA, SOT

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.60~0.78 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 2 :	0.78 / Piece
2 ~ 200 :	0.60 / Piece

PartNumber:: SN74AVCH2T45DCUR

Brand:: Texas Instruments - TI | Pack: SOT | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. hellen's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-23

From Other Seller

Part Number:SN74AVCH2T45DCUR
US $0.60 - 0.78
Quantity:

piece

Product Summary

The SN74AVCH2T45DCUR is a dual-bit dual-supply bus transceiver with configurable voltage translation and 3-state ouputs. The SN74AVCH2T45DCUR uses two separate configurable power-supply rails. The SN74AVCH2T45DCUR is optimizedto operate with VCCA/VCCB set at 1.4V to 3.6V. The SN74AVCH2T45DCUR is designed for asynchronous communication between data buses.

Parametrics

SN74AVCH2T45DCUR absolute maximum ratings: (1) Supply voltage range VCCA, VCCB: -0.5 to 4.6V; (2) Supply voltage range VI: -0.5 to 4.6V (I/O ports (A port) , I/O ports(B port) ; (3) Voltage range applied to any output in the high-impedance or power-off state: -0.5 to 4.6V; (4) Voltage range applied to any output in the high or low state: -0.5 to VCCA +0.5A (A port) , 0.5 VCCB +0.5V (B port) ; (5) Input clamp current IIK: -50mA ( VI<0) , Output clamp current: -50mA (VO<0) ; (6) Storage temperature range: -65 to 150°C.

Features

SN74AVCH2T45DCUR features: (1) Available in the Texas Instruments NanoStar and NanoFree Package; (2) Control Inputs VIH/VIL LevelsAreReference to VCCA Voltage; (3) Fully Configurable Dual-Rail Design Allows Each Port to Operate Over the Full 1.2-V to 3.6-V Power-Supply Range; (4) I/Os Are 4.6-V Tolerant; (5) Ioff Supports Partial-Power-Down Mode; (6) Bus Hold on Data Inputs Eliminates the Need for External Pull up/Pull down Resistors; (7) Latch-Up Performance Exceeds 100mA Per JESD78, ClassII; (8) ESD Protection Exceeds JESD22.
