Product Summary

blf1046 is a Schottky Barrier rectifier.

Parametrics

blf1046 absolute maximum ratings: (1)Ratings at 25℃ ambient temperature unless otherwise specified; (2)Single phase,half wave, 60 Hz, resistive or inductive load; (3)For capacitive load, derate by 20%℃; (4)Maximum recurrent peak reverse voltage: 45V; (5)Maximum average forw ard rectified current: 10A; (6)Typical thermal resistance: 5.0℃/W; (7)Storage temperature range: -55--- + 150℃.

Features

blf1046 features: (1)Metal-Semiconductor junction with guard ring; (2)Epitaxial construction; (3)Low forward voltage drop, low switching losses; (4)High surge capability; (5)For use in low voltage, high frequency inverters free xxxx wheeling, and polarity protection applications; (6)The plastic material carries U/L recognition 94V-0.

Diagrams

blf1046 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
BLF1046
BLF1046
NXP Semiconductors
Transistors RF MOSFET Power RF LDMOS 45W UHF
Data Sheet
Negotiable
BLF1046,112
BLF1046,112
NXP Semiconductors
Transistors RF MOSFET Power RF LDMOS 45W UHF
Data Sheet
0-41: $43.52
41-100: $40.66
BLF1046,135
BLF1046,135
NXP Semiconductors
Transistors RF MOSFET Power TRANSISTOR UHF PWR LDMOS
Data Sheet
0-243: $47.90
