MRF652

N–Channel Enhancement–Mode Lateral MOSFET, 65 Vdc, 159W, NI-600

Rated 5 Rating 5 | reviews | Write a review

Price:: US $14.48~14.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	14.50 / Piece
101 ~ 1000 :	14.49 / Piece
1001 ~ 2000 :	14.48 / Piece

PartNumber:: MRF652

Brand:: Motorola, Inc - Motorola | Pack: SMD | D/C: 04+

Availability:: Supply Ability: 2000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. hellen's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-23

From Other Seller

Part Number:MRF652
US $14.48 - 14.50
Quantity:

piece

Product Summary

The mrf652 is an N–Channel Enhancement–Mode Lateral MOSFET. Designed for GSM 900 frequency band, the high gain and broadband performance of these devices make them ideal for large–signal, common source amplifier applications in 26 volt base station equipment.

Parametrics

mrf652 absolute maximum ratings: (1)Drain–Source Voltage VDSS: 65 Vdc; (2)Gate–Source Voltage VGS: ±20 Vdc; (3)Drain Current — Continuous ID: 7 Adc; (4)Total Device Dissipation PD: 159W @ TC ≥ 25°C; 0.9W/°C; (5)Derate above 25°C; (6)Storage Temperature Range Tstg: –65 to +150 °C; (7)Operating Junction Temperature TJ: 200 °C.

Features

mrf652 features: (1)Specified Performance @ Full GSM Band, 921–960 MHz, 26 Volts; (2)Output Power, P1dB — 80 Watts (Typ); (3)Power Gain @ P1dB — 16 dB (Typ); (4)Efficiency @ P1dB — 58% (Typ); (5)Available in Tape and Reel. R3 Suffix = 250 Units per 32 mm, 13 inch Reel.
