MRF6S9130HR3

RF power, field effect transistor, multicarrier amplifier, RoHS Compliant, 389 W, -0.5, +68 Vdc

Rated 5 Rating 5 | reviews | Write a review

Price:: US $7.48~7.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	7.50 / Piece
101 ~ 1000 :	7.49 / Piece
1001 ~ 2000 :	7.48 / Piece

PartNumber:: MRF6S9130HR3

Brand:: Freescale Semiconductor, Inc - Freescale | Pack: | D/C: 10+

Availability:: Supply Ability: 2000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. hellen's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-20

From Other Seller

Part Number:MRF6S9130HR3
US $7.48 - 7.50
Quantity:

piece

Product Summary

The mrf6s9130hr3 is the RF power field effect transistor which is designed N-CDMA, GSM and GSM EDGE base station applications with frequencies from 865 to 960 MHz. And it is uitable for multicarrier amplifier applications.

Parametrics

mrf6s9130hr3 absolute maximum ratings: (1)Drain-Source Voltage: -0.5, +68 Vdc; (2)Gate-Source Voltage: -0.5, +12 Vdc; (3)Total Device Dissipation @ TC = 25℃: 389 W; (4)Derate above 25℃: 2.2 W/℃; (5)Storage Temperature Range: - 65 to +150℃; (6)Case Operating Temperature: 150 ℃; (7)Operating Junction Temperature: 200℃.

Features

mrf6s9130hr3 features: (1)Characterized with Series Equivalent Large-Signal Impedance Parameters; (2)Internally Matched for Ease of Use; (3)Qualified Up to a Maximum of 32 VDD Operation; (4)Integrated ESD Protection; (5)Lower Thermal Resistance Package; (6)Low Gold Plating Thickness on Leads, 40μ Nominal.; (7)RoHS Compliant; (8)In Tape and Reel. R3 Suffix = 250 Units per 56 mm, 13 inch Reel.
