Product Summary

The mrf754 is an NPN silicon RF transisitor designed for UHF Large Signal Amplifier. Application from 407 to 512 MHz, and 5.0 to 10V.

Parametrics

mrf754 absolute maximum ratings: (1)Ic: 200mA; (2)Vce: 13V; (3)Pdiss: 2.5W@Tc=25℃; (4)Tj: -65℃ to +150℃; (5)TSTG: -65℃ to +150℃; (6)JC: 28.5 OC/W.

Features

mrf754 features: (1)High power gain; (2)Infinite VSWR.

Diagrams

mrf754 block diagram
