MRF897R

MRF897R, NPN silicon RF power transisitor, Motorola, TO, 30 Vdc, 800 – 970 MHz, 105W

Rated 5 Rating 5 | reviews | Write a review

Price:: US $9.20~9.22 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	9.22 / Piece
101 ~ 1000 :	9.21 / Piece
1001 ~ 2000 :	9.20 / Piece

PartNumber:: MRF897R

Brand:: Motorola, Inc - Motorola | Pack: TO | D/C: 02+

Availability:: Supply Ability: 2000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. hellen's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-24

From Other Seller

Part Number:MRF897R
US $9.20 - 9.22
Quantity:

piece

Product Summary

The mrf897r is a RF power transistor. Designed for 24 Volt UHF large–signal, common emitter, class–AB linear amplifier applications in industrial and commercial FM/AM equipment operating in the range 800–970 MHz.

Parametrics

mrf897r absolute maximum ratings: (1)Collector–Emitter Voltage VCEO: 30 Vdc; (2)Collector–Emitter Voltage VCES: 60 Vdc; (3)Emitter–Base Voltage VEBO: 4.0 Vdc; (4)Collector–Current — Continuous IC: 4.0 Adc; (5)Total Device Dissipation, PD: 105W @ TC = 25°C; 0.60W/°C Derate above 25°C; (6)Storage Temperature Range Tstg: –65 to +150 °C.

Features

mrf897r features: (1)Characterized with Series Equivalent Large–Signal Parameters from 800 to 960 MHz; (2)Silicon Nitride Passivated; (3)100% Tested for Load Mismatch Stress at all Phase Angles with 5:1 VSWR @ 26 Vdc, and Rated Output Power; (4)Gold Metalized, Emitter Ballasted for Long Life and Resistance to Metal–Migration; (5)Circuit board photomaster available upon request by contacting RF Tactical Marketing in Phoenix, AZ.
