Product Summary

The IRLZ14 is a Power MOSFET. It provides the designer with the best combination of fast switching, ruggedized device design, low on-resistance and cost-effectiveness. The TO-220AB package is universally preferred for all commercial-industrial applications at power dissipation levels to approximately 50 W. The low thermal resistance and low package cost of the TO-220AB contribute to its wide acceptance throughout the industry.

Parametrics

IRLZ14 absolute maximum ratings: (1)Drain-Source Voltage: 60V; (2)Gate-Source Voltage VGS: ± 10 V; (3)Pulsed Drain Current a IDM: 10 A; (4)Linear Derating Factor: 0.29 W/°C; (5)Single Pulse Avalanche Energy b EAS: 39.5 mJ; (6)Maximum Power Dissipation TC = 25 °C PD: 43 W; (7)Peak Diode Recovery dV/dt c dV/dt: 4.5 V/ns; (8)Operating Junction and Storage Temperature Range TJ, Tstg: - 55°C to + 175 °C; (9)Soldering Recommendations (Peak Temperature)d for 10 s: 300 °C.

Features

IRLZ14 features: (1)Dynamic dV/dt Rating; (2)Logic-Level Gate Drive; (3)RDS(on)Specified at VGS = 4 V and 5 V; (4)175 °C Operating Temperature; (5)Fast Switching; (6)Ease of Paralleling; (7)Simple Drive Requirements; (8)Compliant to RoHS Directive 2002/95/EC.

Diagrams

IRLZ14 plackage dimensions

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
IRLZ14
IRLZ14

Vishay/Siliconix

MOSFET N-Chan 60V 10 Amp

Data Sheet

0-445: $1.51
445-500: $1.36
500-1000: $1.07
1000-2000: $0.99
IRLZ14, SiHLZ14
IRLZ14, SiHLZ14

Other


Data Sheet

Negotiable
IRLZ14PBF
IRLZ14PBF

Vishay/Siliconix

MOSFET N-Chan 60V 10 Amp

Data Sheet

0-1: $0.55
1-10: $0.42
10-100: $0.37
100-250: $0.32
IRLZ14S
IRLZ14S

Vishay/Siliconix

MOSFET N-Chan 60V 10 Amp

Data Sheet

Negotiable
IRLZ14L
IRLZ14L

Vishay/Siliconix

MOSFET N-Chan 60V 10 Amp

Data Sheet

Negotiable
IRLZ144NPbF
IRLZ144NPbF

Other


Data Sheet

Negotiable
IRLZ14SPBF
IRLZ14SPBF

Vishay/Siliconix

MOSFET N-Chan 60V 10 Amp

Data Sheet

0-1: $0.62
1-10: $0.56
10-100: $0.50
100-250: $0.47
IRLZ14STRRPBF
IRLZ14STRRPBF

Vishay/Siliconix

MOSFET N-Chan 60V 10 Amp

Data Sheet

Negotiable
