Product Summary

The RJK0328DPB-01-J0 is a silicon N channel power MOS FET power switch.

Parametrics

RJK0328DPB-01-J0 absolute maximum ratings: (1)Drain to source voltage VDSS: 30 V; (2)Gate to source voltage VGSS: ±20 V; (3)Drain current ID: 60 A; (4)Drain peak current ID(pulse): 240 A; (5)Body-drain diode reverse drain current IDR: 60 A; (6)Avalanche current IAP: 30 A; (7)Avalanche energy EAR: 90 mJ; (8)Channel dissipation Pch: 65 W; (9)Channel to Case Thermal Resistance θch-C: 1.93 ℃/W; (10)Channel temperature Tch: 150 ℃; (11)Storage temperature Tstg: –55 to +150 ℃.

Features

RJK0328DPB-01-J0 features: (1)High speed switching; (2)Capable of 4.5 V gate drive; (3)Low drive current; (4)High density mounting; (5)Low on-resistance; (6)RDS(on) = 1.6 mtyp. (at VGS = 10 V); (7)Pb-free.

Diagrams

RJK0396DPA-00#J53
RJK0396DPA-00#J53

MOSFET N-CH 30V 30A W-PAK
Data Sheet
0-1: $0.44
1-10: $0.38
10-25: $0.34
25-100: $0.30
100-250: $0.26
250-500: $0.22
500-1000: $0.17
