IRFR9024N

IRFR9024N, HEXFET Power MOSFET, DPAK, -55V, -11A, International Rectifier

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.09~0.30 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.09~0.30

PartNumber:: IRFR9024N

Brand:: International Rectifier - IR | Pack: TO | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. hellen's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-11-15

From Other Seller

Part Number:IRFR9024N
US $0.09 - 0.30
AT45DB161D-SU

US $1.50 - 3.50 / Piece
(0) Remove
HEF4093BT

US $0.15 - 1.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The IRFR9024N is a Fifth Generation HEXFET from International Rectifier utilize advanced processing techniques to achieve extremely low on-resistance per silicon area. This benefit, combined with the fast switching speed and ruggedized device design that the IRFR9024NPBF is well known for, provides the designer with an extremely efficient and reliable device for use in a wide variety of applications. The IRFR9024N is designed for surface mounting using vapor phase, infrared, or wave soldering techniques. The straight lead version (IRFU series) is for throughhole mounting applications. Power dissipation levels up to 1.5 watts are possible in typical surface mount applications.

Parametrics

IRFR9024N absolute maximum ratings: (1)ID @ TC = 25℃ Continuous Drain Current, VGS @ -10V: -11A; (2)ID @ TC = 100℃ Continuous Drain Current, VGS @ -10V: -8 A; (3)Pulsed Drain Current, IDM: -44A; (4)PD @TC = 25℃ Power Dissipation 38 W; (5)Linear Derating Factor: 0.30 W/℃; (6)Gate-to-Source Voltage, VGS: ±20 V; (7)Single Pulse Avalanche Energy, EAS: 62 mJ; (8)Avalanche Current, IAR: -6.6 A; (9)Repetitive Avalanche Energy, EAR: 3.8 mJ; (10)Peak Diode Recovery dv/dt, dv/dt: -10 V/ns; (11)Operating Junction and Storage Temperature Range, TJ, TSTG: -55 to + 150℃; (12)Soldering Temperature, for 10 seconds 300 (1.6mm from case℃).

Features

IRFR9024N features: (1)Ultra Low On-Resistance; (2)P-Channel; (3)Surface Mount (IRFR9024N); (4)Straight Lead (IRFU9024N); (5)Advanced Process Technology; (6)Fast Switching; (7)Fully Avalanche Rated; (8)Lead-Free.
