Product Summary

The LM6321M is a high speed unity gain buffer slew at 800V/μs and has a small signal bandwidth of 50MHz while driving a 50Ω load. The LM6321M can drive ±300mA peak and do not oscillate while driving large capacitive loads. Applications of the LM6321M include: line driving, radar and sonar.

Parametrics

LM6321M absolute maximum ratings: (1) Supply Voltage: 36V (±18V) ; (2) Input to Output Voltage: ±7V; (3) Input Voltage: ±V supply; (4) Output Short-Circuit to GND: Continuous; (5) Storage Temperature Range: -65 to +150°C; (6) Lead Temperature (Soldering, 10seconds) : 260°C; (7) ESD Tolerance: ±2000V; (8) Junction Temperature (Tj (max) ) : 150°C.

Features

LM6321M features: (1) High slew rate: 800V/μs; (2) Wide bandwidth: 50MHz; (3) Slew rate and bandwidth 100% tested; (4) Peak output current: ±300mA; (5) High input impedance:50Ω; (6) LH0002H pin compatible; (7) No oscillation swith capacitive loads; (8) 5V to ±15V operation guaranteed; (9) Current and thermal limiting; (10) Fully specified to drive 50Ω.

Diagrams

LM6321M  Pin Configuration
