MAX232CSE

SOP, 5V-Powered, Multichannel RS-232 Drivers/Receivers, -0.3V to +6V, 5μW

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.20~0.25 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.20~0.25

PartNumber:: MAX232CSE

Brand:: Maxim Integrated Products - Maxim | Pack: SOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. hellen's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-14

From Other Seller

Part Number:MAX232CSE
US $0.20 - 0.25
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MAX232CSE line driver/receiver is intended for all EIA/TIA-232E and V28/V24 communications interfaces, particularly applications where ±12V is not available. These parts are especially useful in battery-powered systems, since their low-power shutdown mode reduces power dissipation to less than 5μW. The MAX232CSE uses no external components and are recommended for applications where printed circuit board space is critical.

Parametrics

MAX232CSE absolute maximum ratings: (1)Supply Voltage (VCC): -0.3V to +6V; (2)V+: (VCC - 0.3V) to +14V; (3)V: +0.3V to +14V; (4)Input Voltages; (5)TIN: -0.3V to (VCC - 0.3V); (6)RIN (Except MAX220): ±30V; (7)RIN (MAX220): ±25V; (8)TOUT (Except MAX220): ±15V; (9)TOUT (MAX220): ±13.2V; (10)Output Voltages; (11)TOUT: ±15V; (12)ROUT: -0.3V to (VCC + 0.3V); (13)Driver/Receiver Output Short Circuited to GND: Continuous; (14)Storage Temperature Range: -65℃ to +160℃; (15)Lead Temperature (soldering, 10s): +300℃.

Features

MAX232CSE features: (1)For Low-Voltage, Integrated ESD Applications MAX3222E/MAX3232E/MAX3237E/MAX3241E/MAX3246E: +3.0V to +5.5V, Low-Power, Up to 1Mbps, True RS-232 Transceivers Using Four 0.1μF External Capacitors; (2)For Low-Cost Applications MAX221E: ±15kV ESD-Protected, +5V, 1μA, Single RS-232 Transceiver with AutoShutdown.
