MAX3491ESD

transcevier, 3.3V, +5V, 727mW, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.60~0.78 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 2 :	0.78 / Piece
2 ~ 600 :	0.60 / Piece

PartNumber:: MAX3491ESD

Brand:: Maxim Integrated Products - Maxim | Pack: SOP | D/C: 10+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. hellen's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-21

From Other Seller

Part Number:MAX3491ESD
US $0.60 - 0.78
Quantity:

piece

Product Summary

The MAX3491ESD is a 3.3V, low-power transceiver for RS-485 and RS-422 communication. The MAX3491ESD features slew-rate-limited dri-vers that minimize EMI and reduce reflections caused by improperly terminated cables, allowing error-free data transmission at data rates up to 250kbps. Applications of the MAX3491ESD include: Low-Power RS-485/RS-422 Transceivers, Telecommunications, Transceivers for EMI-Sensitive Applications and Industrial-Control Local Area Networks.

Parametrics

MAX3491ESD absolute maximum ratings: (1) Supply Voltage (VCC) : 7V; (2) Control Input Voltage (RE, DE) : -0.3 to 7V; (3) Driver Input Voltage (DI) : -0.3 to 7V; (4) Driver Output Voltage (A, B, Y, Z) : -7.5 to 12.5V; (5) Receiver Input Voltage (A, B) : -7.5 to 12.5V; (6) Receiver Output Voltage (RO) : -0.3 to (Vcc +0.3V) ; (7) Operating Temperature Ranges: -40°C to +85°C; (8) Storage Temperature Range: -65 to +160°C; (9) Lead Temperature (soldering, 10sec) : +300°C.

Features

MAX3491ESD features: (1) Operate from a Single 3.3V Supply—No Charge Pump; (2) Interoperable with +5V Logic; (3) 8ns Max Skew (MAX3485/MAX3490/MAX3491) ; (4) Slew-Rate Limited for Errorless Data Transmission; (5) -7V to +12V Common-Mode Input Voltage Range; (6) Allows up to 32 Transceivers on the Bus; (7) Full-Duplex and Half-Duplex Versions Available; (8) Current-Limiting and Thermal Shutdown for Driver Overload Protection.
