Product Summary
The SN74ACT373PWR is an 8-bit latch. It features 3-state outputs designed specifically for driving highly capacitive or relatively low-impedance loads. The SN74ACT373PWR is particularly suitable for implementing buffer registers, I/O ports, bidirectional bus drivers, and working registers.
Parametrics
SN74ACT373PWR absolute maximum ratings: (1)Supply voltage range, VCC –0.5 V to 7 V; (2)Input voltage range, VI (see Note 1) –0.5 V to VCC + 0.5 V; (3)Output voltage range, VO (see Note 1) –0.5 V to VCC + 0.5 V ; (4)Input clamp current, IIK (VI < 0 or VI > VCC) ±20 mA; (5)Output clamp current, IOK (VO < 0 or VO > VCC) ±20 mA; (6)Continuous output current, IO (VO = 0 to VCC) ±50 mA; (7)Continuous current through VCC or GND ±200 mA; (8)Package thermal impedance, θJA: DB package 70℃; (9)Storage temperature range, Tstg –65 to 150℃.
Features
SN74ACT373PWR features: (1)4.5-V to 5.5-V VCC Operation; (2)Inputs Accept Voltages to 5.5 V; (3)Max tpd of 10 ns at 5 V; (4)Inputs Are TTL-Voltage Compatible.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SN74ACT373PWR |
Texas Instruments |
Latches Tri-St Octal D-Type |
Data Sheet |
|
|
|||||||||||||
SN74ACT373PWRE4 |
Texas Instruments |
Latches Tri-St Octal D-Type |
Data Sheet |
|
|
|||||||||||||
SN74ACT373PWRG4 |
Texas Instruments |
Latches Octal D-Type Transp |
Data Sheet |
|
|
