Product Summary
The ST19AF08BER2QMAA is a Smartcard MCU With 4 additional I/0. The ST19AF08BER2QMAA is a serial access microcontroller especially designed for very large volume and cost competitive secure portable objects. The ST19AF08BER2QMAA is based on a STMicroelectronics 8 bit CPU core including on-chip memories: 960 Bytes of RAM, 32 K Bytes of USER ROM and 8 K Bytes of EEPROM.
Features
ST19AF08BER2QMAA features: (1)enhanced 8 Bit CPU with extended addressing modes; (2)32 K Bytes of user rom with partitioning; (3)system ROM ; (4)960 Bytes of user ram with partitioning; (5)8 K bytes of user eeprom with partitioning; (6)security firewalls for memories; (7)very high security features including eeprom flash program; (8)8 Bit timer with interrupt capability; (9)2 serial access, ISO 7816-3 compatible; (10)3V ± 10% or 5V ± 10% supply voltage; (11)power saving standby mode; (12)contact assignment compatible ISO 7816-2; (13)ESD protection greater than 5000V.
Diagrams
 |
