Product Summary
blf1046p is a Schottky Barrier rectifier.
Parametrics
blf1046p absolute maximum ratings: (1)Ratings at 25℃ ambient temperature unless otherwise specified; (2)Single phase,half wave, 60 Hz, resistive or inductive load; (3)For capacitive load, derate by 20%℃; (4)Maximum recurrent peak reverse voltage: 45V; (5)Maximum average forw ard rectified current: 10A; (6)Typical thermal resistance: 5.0℃/W; (7)Storage temperature range: -55--- + 150℃.
Features
blf1046p features: (1)Metal-Semiconductor junction with guard ring; (2)Epitaxial construction; (3)Low forward voltage drop, low switching losses; (4)High surge capability; (5)For use in low voltage, high frequency inverters free xxxx wheeling, and polarity protection applications; (6)The plastic material carries U/L recognition 94V-0.
Diagrams
