Product Summary

The 5005251100 is a Micro-Fit 3.0 Header.

Parametrics

5005251100 absolute maximum ratings: (1)Current - Maximum per Contact 5A; (2)Voltage - Maximum 250V.

Features

5005251100 features: (1)Product Family PCB Headers; (2)Series 43650; (3)Application Wire-to-Board; (4)Comments High Temperature|Square Pin|Solder Type; (5)Overview microfit_30; (6)Product Literature Order No USA-106; (7)Product Name Micro-Fit 3.0.

Diagrams

5005251100 block diagram
